Electronics Laboratory

Technology Gallery

Click on each image for a larger view

The images published here are low resolution in order to maximize the number of images in the 5MB of space web allotted. The scanned master copy of these images are of siabgnificantly higher quality than those published here.

Technology Images:

1953, Book Cover, "Principles of Transistor Circuits"	10/23/1953, Authors of 1953 Transistor Book on E-Lab Lobby Stairs	1957, Book Cover, "Transistor Circuit Engineering"
1966 SHOPAIR Chemical Agent Alarm signed poster presented to Dick Sharman	196x, GE Medical Pacemaker (Elab Design)	4/27/1973, GE News Article Celebrating 20th Anniversary of First Transitor Book Publication

   Technology Snippets (to submit snippets, please use this MS Word Template):

Acoustic Holograms: A snippet by Steve Tehon: Lew Somers and I, at the time of enthusiasm about the new discovery of holograms in the 1960s, talked it over, and decided what amounts to "a wave is a wave is a wave." So, we set out to make acoustic holograpms, in water and with ultrasound waves. We got a steel GI barrel, filled it with water, set it up with acoustic senders and recorders, for night runs in the basement of the Lab to avoid much as possible vibrations from traffic in Electronics Parkway. We got recorded patterns, but couldn't make sense out of them. At this point, Bill Penn took a careful look, and said that our problem was that speed of sound (i.e.ultrasound) is so very much slower than light, that to get images from our "acoustic holograms" we would need to observe them with very high gain through a microscope.) Our time was up, our little money was gone, so that was it!
